2 part pressed hinge, mild steel

£2.47£10.24

Clear
Product Code : 2PH
Category:

Description

This is a 2 part lift off hinge with removable steel pin.

KEY FEATURES
  • Dimensions are as follow; (Length x overall width x pin diameter x material thickness)
    60 x 18 x 5.8 x 2mm (90kg capacity per hinge)
    80 x 22 x 8 x 2mm (100kg capacity per hinge)
    100 x 25.5 x 8.8 x 2mm (150kg capacity per hinge)
    140 x 30 x 11 x 2.5mm (200kg capacity per hinge)
    170 x 32 x 12 x 3mm (220kg capacity per hinge)
    200 x 36 x 14 x 3mm (250kg capacity per hinge)
PRODUCT OPTIONS
  • 2PH – 2 part pressed hinge, mild steel

Additional information

Weight 100 g
Size

, , , , ,
